To use Ark in a Go project, run:

go get github.com/mlange-42/ark

Below is the classical Position/Velocity example that every ECS shows in the docs.

See the User Guide, API docs and examples for details.

package main

import (
	"math/rand/v2"

	"github.com/mlange-42/ark/ecs"
)

// Position component
type Position struct {
	X float64
	Y float64
}

// Velocity component
type Velocity struct {
	X float64
	Y float64
}

func main() {
	// Create a new World
	world := ecs.NewWorld()

	// Create a component mapper
	// Save mappers permanently and re-use them for best performance
	mapper := ecs.NewMap2[Position, Velocity](&world)

	// Create entities
	for range 1000 {
		// Create a new Entity with components
		_ = mapper.NewEntity(
			&Position{X: rand.Float64() * 100, Y: rand.Float64() * 100},
			&Velocity{X: rand.NormFloat64(), Y: rand.NormFloat64()},
		)
	}

	// Create a filter
	// Save filters permanently and re-use them for best performance
	filter := ecs.NewFilter2[Position, Velocity](&world)

	// Time loop
	for range 5000 {
		// Get a fresh query
		query := filter.Query()
		// Iterate it
		for query.Next() {
			// Component access through the Query
			pos, vel := query.Get()
			// Update component fields
			pos.X += vel.X
			pos.Y += vel.Y
		}
	}
}
  • ark-serde provides JSON serialization and deserialization for Ark’s World.
  • ark-tools provides systems, a scheduler, and other useful stuff for Ark.
  • ark-pixel provides OpenGL graphics and live plots via the Pixel game engine.

Lange, M. & contributors (2025): Ark – An archetype-based Entity Component System for Go. DOI: 10.5281/zenodo.14994239, GitHub repository: https://github.com/mlange-42/ark

Ark and all its sources and documentation are distributed under the MIT license and the Apache 2.0 license, as your options.
